DCG Series Air Conditioner (Integrated tent air conditioning)

Feature

DCG tent air conditioning
DCG Series Air Conditioner (Integrated tent air conditioning) DCG Series Air Conditioner (Integrated tent air conditioning) DCG Series Air Conditioner (Integrated tent air conditioning) DCG Series Air Conditioner (Integrated tent air conditioning) DCG Series Air Conditioner (Integrated tent air conditioning) DCG Series Air Conditioner (Integrated tent air conditioning) DCG Series Air Conditioner (Integrated tent air conditioning) DCG Series Air Conditioner (Integrated tent air conditioning) DCG Series Air Conditioner (Integrated tent air conditioning) DCG Series Air Conditioner (Integrated tent air conditioning) DCG Series Air Conditioner (Integrated tent air conditioning) DCG Series Air Conditioner (Integrated tent air conditioning) DCG Series Air Conditioner (Integrated tent air conditioning) DCG Series Air Conditioner (Integrated tent air conditioning) DCG Series Air Conditioner (Integrated tent air conditioning) DCG Series Air Conditioner (Integrated tent air conditioning)

G series

Each Drez  product has the feature of 3E(Efficient, Economic, Environmental friendly).

G series has the longest history in Drez air-con development and upgraded to the 8th generation in 2020 for its ultimate and versatile performance more than floor standing.

Minute install and portable floor standing, button touch LCD screen operation.

Optional position of half inside or free inside and suitable to various tent PVC cover or wall.

Present more air flow volume and distance, by chamber box with nozzles, louvre, flexible air duct or insulated tunnel.

Capable for heavy duty use and 24hr running, full galvanized&painting steel frame, HQ aluminum fins and scroll compressor, low noise and huge volume fan, R410a or R407c factory precharged.

Stable performance with wider ambient temperature range over 50 degrees(-15~55Celsius).

Widely applied to any frame and inflatable tent, light steel structure, culture&entertainment, exhibition &event, warehouse&workshop, military and emerency relief.

Parameter

Cooling capacity
Power input
Power specification
Dimension
Weight
Noise
Temperature
Refrigerant
42Kw / 15Hp / 12Ton / 144000Btu
14Kw / 26Amp
220~460V / 3N / 50~60Hz
1.1*2.1*1.9M / 3.6*6.9*6.2Ft
500Kg
<65Db
15~43℃ / 60~110℉
R410a
56Kw / 20Hp / 16Ton / 192000Btu
19Kw / 36Amp
600Kg
70Kw / 25Hp / 20Ton / 240000Btu
24Kw / 46Amp
700Kg
84Kw / 30Hp / 24Ton / 288000Btu
29Kw / 55Amp
1.1*2.1*1.9M / 3.6*6.9*6.2Ft
850Kg
105Kw / 36Hp / 30Ton / 360000Btu
35Kw / 68Amp
1000Kg
116Kw / 40Hp / 32Ton / 384000Btu
38Kw / 72Amp
1.1*2.1*1.9M / 3.6*6.9*6.2Ft
1180Kg
130Kw / 45Hp / 36Ton / 432000Btu
43Kw / 82Amp
1280Kg
145Kw / 50Hp / 40Ton / 480000Btu
48Kw / 92Amp
1360Kg
220Kw / 75Hp / 60Ton / 720000Btu
74Kw / 104Amp
1.1*2.1*1.9M / 3.6*6.9*6.2Ft
1820Kg

Detail and Case

Tent air conditioning cooling in catering event
Catering event
Hydophilic alu fin
Hydrophilic alu fin
Button touch screen
Button touch screen
Compact control board
Compact control board
Drez air conditioning cools down in exhibition tents
Service&repair pit

Galvanize paint frame
Galvanize paint frame
Scroll compressor
Scroll compressor
Tent air conditioning cooling in commercial show
Commercial show

Air conditioning cooling in the wedding tent
Wedding banquet
Air conditioning for workshop
Workshop
Loof air conditioning for sports center
Sports center

Roof air conditioning cooling unit
Warehouse
Nozzles chamber
Nozzles chamber
Outdoor activity tent air conditioning cooling unit
Tennis court

The air conditioning cooling of the Drez tent in the warehouse
Exhibition center
Air conditioning for workshop
Workshop
Industrial air conditioning using air ducts for ventilation
Studio
Tent air conditioning for exhibition hall
Exhibition hall
